S430 Pitot Tube Flow/Consumption Sensor

S430 Pitot Tube Flow/Consumption Sensor

The S430 is a sensor that uses the pitot tube principle of flow measurement. This sensor is designed to measure wet and dirty gases, as found in locations like the compressor discharge.

  • Reliable: ideal for compressor performance tests
  • Simple: effective, inexpensive, and fast measurements
  • Accurate: detailed metrics designed unpredictable outputs

Description

S430 Pitot Tube Flow/Consumption Sensor

Description

The S430 utilizes the pitot tube principle to measure wet and dirty gases that are found in places like the compressor discharge. This sensor boasts long-term reliability, wide turndown ratio, and highly-consistent temperature stability. It can be used in both compressed air and non-corrosive gases, and it can even be installed through a ball valve while the system is still pressurized. Various output signals allow the sensor to be connected to SUTO displays and/or third-party displays and PLCs.

Benefits

Benefit Icon

Faster Testing

Measure compressor outputs with ease

Benefit Icon

Easy to Use

Don’t worry about specialized equipment for smaller jobs

Benefit Icon

Better System Health

Safer for your workers and much easier to manage

Features

Features

  • Flow and consumption measurement in wet air or high mass flow / velocity applications
  • Measurement at compressor outlet
  • Tube diameters of 1.25’’ to 10” through center installation, bigger diameters through non-center installation
  • Insertion type, easy installation under pressure through ball valve possible
  • High temperature applications up to 230°C
  • No mechanical wear parts
  • All parts which are in contact with flow medium are made of stainless steel
  • Compressor-FAD-Measurement
  • Measures Flow, Consumption, Temperature and Pressure

Specs

Specs

  • Flow range:  Refer to table below
  • Pressure range:  0 … 1.6 MPa
  • Temperature range:   -40 … +230°C
  • Accuracy:
    • Flow:  ±(1.5%+0.3% full scale)
    • Pressure:  0.5% F.S.
    • Temperature:  0.5°C
  • Reference conditions: Programmable, default P = 1000 hPa(a), T = 20°C
  • Medium:  Wet and dry air, non-corrosive gasses
  • Output signals:
    • 4 … 20 mA and Pulse (optional)
    • Modbus/RTU (optional)
    • M-Bus (optional)
    • Modbus/TCP (optional)
  • Medium temp.:  -40 … +230°C
  • Ambient temp.:  -20 … +60°C
  • Power supply:  24 VDC, 150 mA
  • Display option:  2.4” color graphic display with keypad
  • Process connection:  3/4” G type (ISO 228-1)
  • Sensor material:  Stainless steel 1.4404 (SUS 316L)
