S418-V Vacuum Flow Meter

S418-V Vacuum Flow Meter

The S418-V Vacuum Flow Meter offers performance monitoring for vacuum pumps . This inline flow meter measures the actual flow and absolute pressure on the low pressure side of a vacuum.

  • Compact: can be installed in hard-to-reach places
  • Integrated: like all SUTO products, you can view measurements from the dashboard
  • Easy to Install: no straight pipe section required

Description

S418-V Vacuum Flow Meter

Description

The S418-V Vacuum Flow Meter offers performance monitoring for vacuum pumps. With a small size and easy installation process, the S418-V is designed to be placed just about anywhere it’s needed. This inline flow meter measures the actual flow and absolute pressure on the low pressure side of a vacuum. Like all SUTO products, it is data-logger integrated.

Benefits

Benefit Icon

Higher Confidence in Metrics

Get measurements from every square inch of your system

Benefit Icon

Faster Monitoring

Easily view the whole system at once

Benefit Icon

Reduce Waste

Instant notification the moment metrics are off

Features

Features

  • Smartphone App:  For remote configuration
  • Compact Design:  Can be installed anywhere
  • Easy Process Monitoring:  Effective and inexpensive recording
  • Point-of-Use Installation:  No straight pipe section required
  • Total Flow:  No bypass measurement
  • Accurate Results:  Integrated flow conditioner

Specs

Specs

  • Inner thread:  DN8, DN15, DN20, DN25
  • Process connection:  G inner thread (ISO 228-1)
  • Pressure range:  0.01 … 1.60 bar(a)
  • Ambient / Transport temperature:  0 … +50°C / -30 … +70°C
  • Medium conditions:  0 … +50°C / rH < 90% no condensation
  • Power supply:  18 … 30 VDC / 120 mA
  • Output signal:
    • (A) Analogue 4 … 20 mA, pulse
    • (B) RS-485 (Modbus/RTU)
    • (C) Digital M-Bus
  • LED display:  4-Digit Flow + Pressure (option)
  • Material:
    • Process connection: aluminum alloy
    • Wetted parts: aluminum alloy
    • Top casing: PC + ABS
  • Classification:  IP54
  • Electrical connection:  2 x M8, 4 poles
  • Approvals:  CE, RoHS
