Serie STS 40
The STS 40 High Pressure Piston Booster delivers reliable high-pressure compressed air up to 580 PSI with power ranges from 15 to 25 HP and airflow from 110 to 273 CFM for demanding industrial applications.
- ✓Power range 15–25 HP with airflow 110–273 CFM and discharge pressure up to 580 PSI.
- ✓Fixed-speed piston booster with high-efficiency IE3 electric motor and low-speed operation for greater durability.
- ✓Cabinet or open-frame version with microprocessor control panel in cabinet models.
- ✓Long-life concentric intake and discharge valves with optional sequential operation.
- ✓2-year booster warranty — reliable performance for harsh industrial environments.
Description
STS 40 High Pressure Piston Booster – Reliable Pressure Boosting up to 580 PSI
The STS 40 series by South-Tek Systems is designed for applications where standard compressed air must be elevated to significantly higher pressure levels, reaching 580 PSI with stable and continuous performance.
Its fixed-speed piston design ensures mechanical robustness and resistance during prolonged operation. The IE3 motor optimizes energy consumption, while low-speed operation reduces internal wear, extending system service life.
Available in either cabinet-mounted or open-frame configuration, the equipment offers installation flexibility according to space availability and environmental noise requirements. The microprocessor-based control panel allows monitoring of key system parameters to ensure reliable performance in critical applications.
Applications
PET blow molding systems.
Hydrostatic and pressure testing.
Automotive industry.
Industrial processes requiring ≥580 PSI.
High-pressure instrumentation applications.
Specialized manufacturing plants.
Continuous industrial operations.
The STS 40 High Pressure Piston Booster is ideal for any application requiring reliable pressure above standard compressor output.
Advantages
Efficient pressure boosting up to 580 PSI.
High reliability in critical applications.
Extended durability through low-speed operation.
Installation flexibility (cabinet or open-frame).
Precise control via microprocessor panel.
Energy efficiency with IE3 motor.
Continuous operation under demanding conditions.
Reduced downtime in high-pressure processes.
Mechanical Engineering for Extreme High Pressure
The STS 40 series by South-Tek Systems incorporates robustly manufactured compressor blocks with concentric suction and discharge valves designed to maximize volumetric efficiency and extend service life under high-pressure conditions.
The motors supplied by WEG S.A. are non-proprietary, facilitating maintenance and spare parts availability. The equipment features Class F insulation for thermal protection during prolonged operation.
The microprocessor-based control system includes:
- Optional touchscreen display
- Integrated phase protection
- Current protection for main motor and fan motor
- ABS enclosure with IP65 protection rating
- MODBUS communication
- IoT integration readiness
The bar-and-plate cooling system improves thermal dissipation, optimizing performance even in high-pressure applications and demanding industrial environments.
Downloads
STS 40 Series Manual
STS 40 Series Catalog
